JMX

JMXメトリクスをFluent BitでElasticsearchへ連携

以下bashを作成JMXメトリクスを取得するcurlをスクリプトにまとめます。

Bashスクリプト化
#!/bin/bash
curl -s -X POST http://localhost:8778/jolokia/ \
  -H 'Content-Type: application/json' \
  -d '[
    { "type": "read", "mbean": "java.lang:type=Memory", "attribute": "HeapMemoryUsage" },
    { "type": "read", "mbean": "java.lang:type=MemoryPool,name=Metaspace", "attribute": "Usage" },
    { "type": "read", "mbean": "java.lang:type=Threading", "attribute": "ThreadCount" },
    { "type": "read", "mbean": "Catalina:name=\"http-nio-8080\",type=ThreadPool", "attribute": "currentThreadCount" },
    { "type": "read", "mbean": "Catalina:name=\"http-nio-8080\",type=ThreadPool", "attribute": "currentThreadsBusy" },
    { "type": "read", "mbean": "Catalina:name=\"http-nio-8080\",type=ThreadPool", "attribute": "connectionCount" },
    { "type": "read", "mbean": "Catalina:name=\"http-nio-8080\",type=GlobalRequestProcessor", "attribute": "requestCount" },
    { "type": "read", "mbean": "Catalina:name=\"http-nio-8080\",type=GlobalRequestProcessor", "attribute": "processingTime" },
    { "type": "read", "mbean": "Catalina:name=\"http-nio-8080\",type=GlobalRequestProcessor", "attribute": "errorCount" },
    { "type": "read", "mbean": "Catalina:name=\"http-nio-8080\",type=GlobalRequestProcessor", "attribute": "bytesReceived" },
    { "type": "read", "mbean": "java.lang:name=PS Scavenge,type=GarbageCollector", "attribute": "CollectionCount" },
    { "type": "read", "mbean": "java.lang:name=PS MarkSweep,type=GarbageCollector", "attribute": "CollectionCount" }
  ]' \
| jq -c '
  {
    timestamp: .[0].timestamp,
    heap_used: .[0].value.used,
    heap_max: .[0].value.max,
    metaspace_used: .[1].value.used,
    metaspace_max: .[1].value.max,
    thread_count: .[2].value,
    tomcat_threads_current: .[3].value,
    tomcat_threads_busy: .[4].value,
    tomcat_connections: .[5].value,
    tomcat_request_count: .[6].value,
    tomcat_processing_time: .[7].value,
    tomcat_error_count: .[8].value,
    tomcat_bytes_received: .[9].value,
    gc_scavenge_count: .[10].value,
    gc_marksweep_count: .[11].value
  }'
-- 実行権限の付与
chmod +x /opt/jmx-metrics/jmx_metrics.sh
スクリプトの動作確認
[root@vm105 jmx-metrics]# /opt/jmx-metrics/jmx_metrics.sh | jq
{
  "timestamp": 1746806735.280342,
  "heap_used": 82441624,
  "heap_max": 954728448,
  "metaspace_used": 23855568,
  "thread_count": 25,
  "tomcat_threads_current": 10,
  "tomcat_threads_busy": 0,
  "tomcat_connections": 1,
  "tomcat_request_count": 72,
  "tomcat_processing_time": 79773,
  "tomcat_error_count": 1,
  "tomcat_bytes_received": 25622,
  "gc_scavenge_count": 2,
  "gc_marksweep_count": 1
}
[root@vm105 jmx-metrics]#
fluent-bit.conf の追記
[SERVICE]
    Flush             1
    Daemon            Off
    Log_Level         info
    Parsers_File      parsers.conf
#   plugins_file      plugins.conf


[INPUT]
    Name               exec
    Tag                jmx.metrics
    Command            /opt/jmx-metrics/jmx_metrics.sh
    Interval_Sec       3
    Buf_Size           10240

# パーサーを作成し
[FILTER]
    Name               parser
    Match              jmxmetrics
    Key_Name           exec
    Parser             jmx_json

[FILTER]
    Name               modify
    Match              jmx.metrics
    Add                source jmx


[OUTPUT]
    Name               stdout
    Match              *
    Format             json_lines

[OUTPUT]
    Name                pgsql
    Match               jmx.metrics
    Host                192.168.56.105
    Port                5432
    User                sooni
    Password            soopass
    Database            soodb
    Table               jmx_metrics
parsers.confへ以下追記

[PARSER]
    Name   jmx_json
    Format json
CREATE TABLE jmx_metrics (
  server_name text,
    execution_time	 TIMESTAMP ,
    metrics JSONB  -- JMXメトリクスをJSONとして格納
);
SELECT
to_timestamp(((metrics->>'exec')::jsonb->>'timestamp')::double precision) AS formatted_time
,(metrics->>'exec')::jsonb->>'heap_used' AS heap_used
,(metrics->>'exec')::jsonb->>'heap_max' AS heap_max
,(metrics->>'exec')::jsonb->>'metaspace_used' AS metaspace_used
,(metrics->>'exec')::jsonb->>'tomcat_connections' AS tomcat_connections
FROM jmx_metrics;
